Applications
Based on the Archimedes buoyancy method, displacement method, saturation method, and wax-sealing method are used for testing various irregular foams, rigid plastic foams, sponges, EVA shoe materials, ceramics, alumina ceramics, powder metallurgy products, polyurethane, insulation materials, refractory materials, rocks, carbon fibers, EPDM rubber and plastics, graphite carbon brushes, magnetic materials, etc.
Specifications&Features
Main technical specifications
1. Weighing range：0.001 - 200g
2. Minimum sample weight：5g
3. Maximum sample weight：200g
4. Water absorption and porosity：0.0001
5. Density measuring range：0.001 - 99.999g/cm³
6. Density resolution：0.001g/cm³
7. Weighing sensor：German HBM
8. A Cage for floating objects：Yes
9. Function for solution compensation：Yes
10.Medium：Either water or liquid
11.Wind-proof outer cover：Yes
12. Standard interface：RS-232C
13. Testing time：10 seconds
14. Temperature setting range： 0 to 100℃
15. Display：LCD
16. Power Supply：AC 220 V, 50 Hz
Main technical features
1. Direct measurement of density (greater or less than 1), porosity, and water absorption of solids, granules, and floaters of any shape.
2. Simple operation with high accuracy and excellent repeatability.
3. Features temperature and solution compensation settings for more user-friendly operation, better meeting the requirements of on-site testing.
4. Equipped with an RS-232C interface for easy connection to a printer.
5. Designed with a large, monolithic testing tank (150*100*70mm) for measuring the density of larger solid objects.
6. Durable, monolithic injection-molded density accessories, resistant to damage and designed for easier operation.
7. Includes a wind shield, making it more suitable for on-site testing.
