Description
Suitable for research institutes, universities, inspection institutes, metrology institutes, enterprises and institutions, widely used in various industries such as plastics, grain, feed, powder, tobacco, paper, food (dehydrated vegetables, meat, noodles, flour, biscuits, stuffing Biscuits, aquatic products processing), tea, beverages, grains, chemical raw materials, pharmaceuticals, textile raw materials, etc., to test the free water contained in the sample.
Main technical specifications
1. Power supply: AC220V,50Hz/AC110V,60Hz
2. Capacity range: 120g
3. Precision: 0.001g
4. Load cell: Electromagnetic force sensor
5. Calibration method: External weight calibration (100g weight)
6. Moisture readability: 0.01%MC
7. Repeatibility: > 1 g: 0.001(0.1%) or
> 2g: 0.0005(0.05%)
8. Principle: Thermal weight loss
9. Temperature range : 40℃ – 200℃
10. Temperature readability: 1℃
11. Heating method: Ring halogen lamp heating
12. Timing set: 1 to 99min(1 min interval)
13. Sample Pan: Ø102mm, stainless steel
14. Display: Moisture content, solid content, drying rate, weight after drying, moisture regain, real-time temperature, graph
15. Shutdown modes: Automatic, timing, manual
16. Communication port: RS232
17. Dimensions and weight: 310×200×205mm,4.3Kg
Main technical features
1. 5.7 inch colored touch LCD operating.
2. Powerful software supplies the functions such as weighing, parts counting, percent weighing, check weighing, animal weighing, totalization, density weighing, formula weighing, target weighing, etc.
3. Multi-user management, can store up to 5000pcs of data. It can display the sensor temperature and do temperature compensation automatically in real time to ensure the accuracy of measurement.
4. Excellent wireless sensing operating function. It can set the automatic correction and peeling function to avoid contamination of the instrument by chemical reagent operating.
5. Electromagnetic balance sensor.
